DIMENSIONS:
2.50mm x 2.50mm x 17.70mm
OPENING ANGLES:
360 degree shaft rotation
INSTALLATION:
M1.6 screw threaded holes x 2
SURFACE FINISH:
Plating finish
CUSTOMIZATION:
- Customized torque is available- Customization of select design elements is also available
CERTIFICATIONS AND COMPLIANCE:
RoHS and REACH compliant
OTHERS:
- Zero backlash
- Minimal or no springback
- One pair of hinges is required for proper function.
TECHNICAL DRAWING:
ENVIRONMENTAL PERFORMANCE:
Operating temperature: -20°C to 65°C
FAQ/SUPPORTS:
Q: Can this friction hinge be made with higher torque?
A: Yes, we can make it with higher torque, up to a maximum of 0.04Nm.
Q: Can this friction hinge be made with two through holes instead of two tapped holes?
A: Yes, we can manufacture it with two through holes instead of tapped holes.
